TEST: Fikwot FN960 2TB M.2 SSD

Here you can find a detailed performance and benchmark test of the M.2 NVMe SSD FN960 with 2TB (FN960-2TB) from Fikwot.
Score
6421
Price/GB
0,06 €


Technical data
Image FN960
Manufacturer Fikwot
Model number FN960-2TB
Storage capacity 2048 GB (1863 GiB)
pSLC-Cache >300 GB approx.
Read speed 4800 MB/s
Write speed 4200 MB/s
Interface PCIe 4.0 x4
Connection M.2 2280
Memory module (NAND) TLC
DRAM Cache no
TBW (Total Bytes Written) 1400 Terabyte
Controller Maxio MAP1608
Price ca. 123 USD (= 0,06 $ / GB)
Paid link Buy on Amazon
Compare Product
Compared to the top performer*
Read speed
66 %
Write speed
67 %

*) Test result evaluated according to AS SSD Score within the same size.

AS SSD Benchmark

Standard performance test

The standard test was performed using a 5 GB file. A total score of 6421 points was achieved.

AS SSD TEST: Fikwot FN960 2TB

AS SSD Read: Write:
Seq
in megabytes per second
4271,06 MB/s
4292,08 MB/s
4K
in megabytes per second
57,44 MB/s
166,78 MB/s
4K-64Thrd
in megabytes per second
2011,78 MB/s
2051,00 MB/s
Access time
in milliseconds
0,023 ms
0,418 ms
Score
2496
2647
Total score
6421

Copy Performance Test

A common everyday situation is simulated here. Three test folders are created:

  • ISO (folder with two large files)
  • Program (folder with many small files)
  • Game (folder with small and large files)

The three folders are copied using the Windows Copy command (the cache remains enabled). The practical test of February 06, 2024 shows the performance for simultaneous write and read operations. The lower the duration, the better the performance.

AS SSD TEST: Fikwot FN960 2TB
AS SSD Copy-Benchmark Transfer rate: Duration:
ISO
two large files
2147,16 MB/s
1,07 s
Program
many small files
1129,51 MB/s
6,23 s
Game
small and large files
1950,45 MB/s
3,54 s

Compression Performance Test

This measures the write and read speed of the the Fikwot SSDSSD is measured depending on the compressibility of the data (according to the manufacturer, these should be 4800MB/s and 4200MB/s respectively).

AS SSD TEST: Fikwot FN960 2TB

CrystalDiskMark Benchmark

Here, two sequential and two random performance tests are performed, similar to the ones performed on the AS SSD.

CrystalDiskMark Benchmark TEST: Fikwot FN960 2TB
CDM Read [MB/s] Write [MB/s]
SEQ1M
Q8T1
4918,32
4711,23
SEQ1M
Q1T1
4389,08
4705,47
RND4K
Q32T16
2946,18
2283,09
RND4K
Q1T1
68,12
187,37

Input/Output operations per second

CDM Read [IOPS] Write [IOPS]
SEQ1M
Q8T1
4.690,50
4.493,00
SEQ1M
Q1T1
4.185,80
4.487,50
RND4K
Q32T16
719.283,00
557.394,00
RND4K
Q1T1
16.630,10
45.745,40

Average latency

CDM Read [µs] Write [µs]
SEQ1M
Q8T1
1.704,19
1.777,00
SEQ1M
Q1T1
238,71
222,61
RND4K
Q32T16
710,52
916,18
RND4K
Q1T1
60,01
21,71

HD Tune Pro Endurance test

This is a long term test to make full use of the memory capacity. You can see when a cache is full and the writing performance decreases. A test file of 300 GB was written to the medium. The exact cache size could not be determined, because the test file did not exhaust the cache (brought it to the limit).At least the test file could be read with an average write speed of 4057 MB/s and written with 3961 MB/s.

HD Tune Endurance Test TEST: Fikwot FN960 2TB

HD Tune Pro Benchmark

HD Tune writes a 5 GB file to the Fikwot M.2 SSD. The transfer data of the read speed is displayed graphically. The minimum, maximum and average values are also determined. The determined access time and burst rate are also displayed.

HD Tune TEST: Fikwot FN960 2TB

ATTO Disk Benchmark

Here, a 256 MB file is written several times to the Fikwot M.2 SSD. The I/O block size varies (from 512 bytes to 64 megabytes). The larger the blocks, the faster they can be written and read.

ATTO Disk Benchmark TEST: Fikwot FN960 2TB

SSD-Z Benchmark

Similar to HD Tune, a 500 MB file is written to the Fikwot M.2 SSD here. The transfer data is displayed. The more constant the line, the better.

SSD-Z TEST: Fikwot FN960 2TB


Information about the test system can be found at the bottom of the home page.
