TEST: Samsung 860 EVO 2TB SATA SSD
Here you can find a detailed performance and benchmark test of the SATA SSD 860 EVO with 2TB (MZ-76E2T0B/EU) from Samsung.802
0,10 €
| Technical data | |
| Image |
|
| Manufacturer | Samsung |
| Model number | MZ-76E2T0B/EU |
| Storage capacity | 2048 GB (1863 GiB) |
| Read speed | 550 MB/s |
| Write speed | 520 MB/s |
| Interface | SATA 6 Gbps |
| Connection | 2.5" |
| Memory module (NAND) | TLC |
| TBW (Total Bytes Written) | 1200 Terabyte |
| Controller | Samsung MJX (S4LR030) |
| Price | ca. 215 USD (= 0,10 $ / GB) |
| Paid link | Buy on Amazon |
Compared to the top performer*
*) Test result evaluated according to AS SSD Score within the same size.
AS SSD Benchmark
Standard performance test
The standard test was performed using a 1 GB file. A total score of 802 points was achieved.
| AS SSD | Read: | Write: |
|---|---|---|
| Seq in megabytes per second |
518,78 MB/s |
458,16 MB/s |
| 4K in megabytes per second |
41,18 MB/s |
87,57 MB/s |
| 4K-64Thrd in megabytes per second |
218,11 MB/s |
184,68 MB/s |
| Access time in milliseconds |
0,043 ms |
0,037 ms |
| Score | 311 |
318 |
| Total score | 802 |
|
Copy Performance Test
A common everyday situation is simulated here. Three test folders are created:
- ISO (folder with two large files)
- Program (folder with many small files)
- Game (folder with small and large files)
The three folders are copied using the Windows Copy command (the cache remains enabled). The practical test of December 01, 2020 shows the performance for simultaneous write and read operations. The lower the duration, the better the performance.
| AS SSD Copy-Benchmark | Transfer rate: | Duration: |
|---|---|---|
| ISO two large files |
931,59 MB/s |
1,15 s |
| Program many small files |
708,18 MB/s |
1,99 s |
| Game small and large files |
1102,54 MB/s |
1,25 s |
Compression Performance Test
This measures the write and read speed of the the Samsung SATA SSDSSD is measured depending on the compressibility of the data (according to the manufacturer, these should be 550MB/s and 520MB/s respectively).
CrystalDiskMark Benchmark
Here, two sequential and two random performance tests are performed, similar to the ones performed on the AS SSD.
| CDM | Read [MB/s] | Write [MB/s] |
|---|---|---|
| SEQ1M Q8T1 |
549,79 |
485,90 |
| SEQ1M Q1T1 |
537,22 |
475,22 |
| RND4K Q32T16 |
229,49 |
195,10 |
| RND4K Q1T1 |
45,02 |
96,57 |
HD Tune Pro Benchmark
HD Tune writes a 1 GB file to the Samsung SATA SSD. The transfer data of the read speed is displayed graphically. The minimum, maximum and average values are also determined. The determined access time and burst rate are also displayed.
ATTO Disk Benchmark
Here, a 256 MB file is written several times to the Samsung SATA SSD. The I/O block size varies (from 512 bytes to 64 megabytes). The larger the blocks, the faster they can be written and read.
Information about the test system can be found at the bottom of the home page.
